Description
| Technical Specifications | |
|---|---|
| Power supply | AC 100 volts – 240 volts |
| Power consumption | Normal operation < 3 W |
| Network protocols | Seekway protocols |
| Data output | SPI TTL / DMX RS-485 / SW MCU / Breakpoint resume Seekway protocol: 8 ports ×3072 channels |
| Supported LED models | “SW MCU: D**S, D**J; Single line: TM180*-400K/800K, UCS19**, UCS29**, WS2811/12, SM167**, SM168**, SM15155E, SM16912P, UCS2603, TM1903, TM1908, SM16714PHT, FL16703A, HW1002A, RT7908A, KW2303A, MT16703, FW1903, FW1935; DMX512: SW-D, SW-U, UCS512A/B/C0/C4/D/E0/EH/G4/G6/H/H4/H4L/KH/KL, DMX512AP/SM512, SM16500P/511/512, SM16522P/PS, SM17500P/512P/522P, SM17512/522, SM18512P/PK, SM18522P/522PH, SM19522PS, Hi512A0/A4/A6/AD/AE/B4L, TM512AB3/AL1/ACx/AD, QED512P, GS8511/512/513/515/516/516B, GS8523/24/25/26, market standards DMX512; Breakpoint resume: UCS5603, WS2818, GS8206, P9883, TM1914, XT1506S. |
| Port | 8 ports (5P Terminal Block × 9, Contains a spare) |
| Ethernet | 2 x RJ45 |
| Transmission distance | Category 5e unshielded network cable, 100 meters between controllers. For longer distances, “fiber converter” can be used, up to 5 kilometers. |
| Shell material | Iron |
| Operate | 4 buttons + 1 working indicator light + 2 network status indicators + 1 audio interface + 1 mic interface + 2 DMX console interface (RJ45) + 1 GPS interface + 1 Bluetooth antenna interface |
| Size | 285 mm ×156 mm × 45 mm (11.23 in× 6.14 in. × 1.77 in.) (L×W×H) |
| Temperature range | -10 degrees Celsius to 70 degrees Celsius (14 degrees Fahrenheit to 158 degrees Fahrenheit) |
| Relative humidity | 5 % to 50 %, non-condensing |
| IP rating | IP20 |
| Warranty | The manufacturer offers a 2-year limited warranty |
